Mobilux™ EP Series

Description

Mobilux™ EP 0, 1, 2, 3, 004 and 023 products are a high-performance family of four general-purpose industrial greases and two special-duty semi-fluid greases. These lithium hydroxystearate greases are formulated to provide extra protection against wear, rusting and water washout. They are available in NLGI grades ranging from 00 to 3, with base oil viscosities ISO VG 150 and 320.

Mobilux EP 0, 1, 2 and 3 greases are recommended for most types of industrial applications including heavy-duty applications where high unit pressures or shock loads are present. These greases provide excellent protection against rust and corrosion and resist water wash-out which makes them particularly suitable for equipment where moist or wet conditions are common. Mobilux EP 0 and 1 are suitable for centralised systems. Mobilux EP 2 and 3 are general-purpose greases. The recommended operating temperature range is from -20ºC to 130ºC but they may be used at higher temperatures if the lubrication frequency is increased accordingly.

Mobilux EP 004 and Mobilux EP 023 are particularly suitable for the lubrication of enclosed gears and bearings in poorly sealed gear cases they can also be used in many other industrial applications where conventional gear oils cannot be retained in gear cases, chain cases, etc. because of leakage due to worn or missing seals. The recommended operating temperature range is -20 to 120ºC for Mobilux EP 004 and -20 to 120ºC for Mobilux EP 023.

Features and Benefits

Mobilux EP greases have a long history of proven performance and have demonstrated good performance in the areas of corrosion protection, low temperature pumpability and high temperature service life. A Timken OK load of 40 lb illustrates their load carrying and extreme pressure capability.

• Reduced wear under heavy or shock loading and vibration for good equipment reliability and availability
• Protection against rust and corrosion and resistance to water washout for equipment protection and good lubrication even in presence of water
• Extended bearing life potential in wet environments for reduced bearing costs and unanticipated downtime
• Good pumpability in centralised systems (Mobilux EP 0 and 1)
• Effective leakage control (Mobilux EP 004 and Mobilux EP 023)

Applications

• Mobilux EP 0 and EP 1 provide good low temperature pumpability and are suitable for centralised lubrication systems and other applications where low temperature performance is
• Mobilux EP 2 is recommended for multipurpose applications in antifriction and plain bearings, bushings and pins under normal operating
• Mobilux EP 3 is a stiffer NLGI grade 3 grease recommended for applications where maximum protection against penetration of water or solid contaminants is
• Mobilux EP 004 and Mobilux EP 023 are particularly suitable for the lubrication of enclosed gears and bearings in poorly sealed gear cases on most underground mining machinery with the exception of electric motor gearings. Mobilux EP 004 and Mobilux EP 023 can also be used in many other industrial applications where conventional gear oils cannot be retained in equipment such as gear cases, chain cases, because of leakage due to worn or missing.Specifications and Approvals


  This product has the following approvals:	MOBILUX EP 0	MOBILUX EP 1	MOBILUX EP 2	MOBILUX EP 3	MOBILUX EP 004	MOBILUX EP 023
  SEW-Eurodrive					X



  This     product     meets     or        exceeds     the requirements of:	MOBILUX EP 0	MOBILUX EP 1	MOBILUX EP 2	MOBILUX EP 3	MOBILUX                   EP 004	MOBILUX                   EP 023
  DIN 51825:2004-06 – KP 1 K -20		X
  DIN 51825:2004-06 – KP 2 K -20			X
  DIN 51825:2004-06 – KP 3 K -20				X
  DIN 51826:2005-01 – GP 000 G -20						X
  DIN 51826:2005-01 – GP 00 G -20					X
  DIN 51826:2005-01 – GP 0 G -20	X



  Properties and Specifications

  Property	MOBILUX EP 0	MOBILUX EP 1	MOBILUX EP 2	MOBILUX EP 3	MOBILUX      EP 004	MOBILUX      EP 023
  Grade	NLGI 0	NLGI 1	NLGI 2	NLGI 3	NLGI 00	NLGI 000
  Thickener Type	Lithium	Lithium	Lithium	Lithium	Lithium	Lithium
  Copper Strip Corrosion, 24 h, 100 C, Rating, ASTM D4048	1A	1A	1A	1A		1A
  Dropping Point, °C, ASTM D2265	190	190	190	190
  Four-Ball Extreme Pressure Test, Weld Point, kgf, ASTM D2596	250	250	250	250	250	250
  Four-Ball Wear Test, Scar Diameter, mm, ASTM D2266	0.4	0.4	0.4	0.4	0.5	0.4
  Penetration, 60X, 0.1 mm, ASTM D217	370	325	280	235	415	460
  SKF Emcor Rust Test, Distilled Water, ASTM D6138	0 , 0	0 , 0	0 , 0	0 , 0	0 , 0	0 , 0
  Timken OK Load, lb, ASTM D2509	40	40	40	40	40	40
  Viscosity @ 100 C, Base Oil, mm2/s, ASTM D445	14.8	14.8	14.8	14.8	14.8	23.4
  Viscosity @ 40 C, Base Oil, mm2/s, ASTM D445	160	160	160	160	160	320
  Viscosity Index, ASTM D2270	91	91	91	91	91	92
